Промышленный медиаконвертор Planet IVC-2004PT

Цена: 20713 руб

Артикул: IVC-2004PT
Производитель:Planet
Доставка: от 800 р. по Москве
Наличие:В наличии

Указанная цена актуальна при заказе от 25 000 руб., при заказе на меньшую сумму, стоимость может измениться в сторону увеличения.

IP30 Industrial Ethernet Extender, 4-Port POE Switch, 1-Port BNC, 1-Port RJ11 (-40 to 75C)


PLANET IVC-2004PT, an Industrial grade Ethernet Extender with PoE supported, is integrated with three advanced technologies:
• Extends Ethernet over coaxial cable or phone wire
• IEEE 802.3af Power over Ethernet
• Industrial wide-ranging operating temperature
The IVC-2004PT is designed to utilize the commonly existed coaxial cables or phone wires to extend the UTP Ethernet over 100m distance limitation and transmits both power and data over single Ethernet cable to remote PoE capable devices in heavy industrial demanding environments.



IEEE 802.3af Power over Ethernet Integrated


The IVC-2004PT provides 4 10/100Mbps copper ports with 4 IEEE 802.3af Power over Ethernet inject interfaces delivered in an IP-30 rugged strong case. Supporting up to 15.4-watt power per port for any remote IEEE 802.3af powered device (PD) such as PoE IP cameras and PoE wireless LAN access point, the IVC-2004PT is an ideal solution to deploying surveillance system, and securing control and wireless service in climatically demanding wide temperature range (-40 to 75 degrees C) environments.


Long-reach Ethernet


To extend the network distance and provide reliable Ethernet networking in hardened environments, the IVC-2004PT is equipped with one asymmetric / symmetric Ethernet extender port. The extender port can be RJ-11 or BNC connector. Customers can use either BNC or RJ-11 for their network deployment and the IVC-2004PT offers the absolutely fastest data transmission speed up to 99/65Mbps over existing coaxial cable and telephone wire without the need of rewiring.



Flexible Combination of Applications


The IVC-2004PT helps users to flexibly re-deploy a new local Intranet in the apartment, intelligent transportation systems, building automation, campus and hospitality environment by applying the original network structure without spending extra cost. The IVC-2004PT can be adjusted to Master or Slave mode via a DIP switch. It also can be set up to connect with the other IVC-2004PT or with other PLANET Ethernet extenders -- the IVC-2002, VC-201A and VC-202A. Therefore, users can easily expand the current network structure easily and more flexibly.
