Коммутатор Planet IGS-801M

Physical Port

• 8-Port 10/100/1000Base-T RJ-45 copper interface

Layer 2 Features

• Supports Auto-Negotiation and Half-Duplex / Full-Duplex modes for all 10Base-T/100Base-TX and 1000Base-T ports
  Auto-MDI/MDI-X detection on each RJ-45 port
  Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE frame flow control (Full-Duplex)
  High performance Store and Forward architecture, broadcast storm control, runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth
  Backplane (Switching Fabric): 16Gbps
  9K Jumbo packet size support
  8K MAC Address Table
  VLANs:

• - IEEE 802.1Q Tag-Based VLAN
  - Up to 64 VLANs groups, out of 4096 VLAN IDs
  - Port-Based VLAN

• Link Aggregation

• - Up to 4 trunk groups
  - Up to 8 ports per trunk group with 16Gbps bandwidth
  - IEEE 802.3ad LACP (Link Aggregation Control Protocol)
  - Cisco ether-channel (Static Trunk)

Spanning Tree Protocol:

• - IEEE 802.1d classic Spanning Tree Algorithm
  - IEEE 802.1w Rapid Spanning Tree Protocol

Quality of Service

• 4 priority queues on all switch ports
  Traffic classification:

• - IEEE 802.1p CoS
  - IP TOS / DSCP

• Strict priority and Weighted Round Robin (WRR) CoS policies

Multicast

• IGMP Snooping v1 and v2
  IGMP Query mode for Multicast Media application

Security

• IEEE 802.1x Port-Based Authentication
  Port Mirroring to monitor the incoming or outgoing traffic on a particular port

Management

• Remote WEB-Based management
  Access through SNMP v1, v2c
  SNMP Trap for alarm notification of events
  Firmware upgrade through web interface
  Cable Diagnostics technology
  Supports Smart-DISCOVERY Utility for deploy management

Industrial Case / Installation

• IP-30 Aluminum case protection
  DIN Rail and Wall Mount Design
  Redundant Power Design
  12 to 48V DC, redundant power with polarity reverse protect function
  Supports EFT protection 6000 VDC for power line
  Supports 6000 VDC Ethernet ESD protection
  -10 to 60 Degree C operation temperature
